Evoguard Single Seat Valves

Call for Price

USED FOR SHUT OFF IN PIPE SYSTEM

HIGH VALVE REQUIREMENTS: PRODUCT PRESSURE UP TO 330PSI (22.7 BAR)

PREVENTION OF PRESSURE BLOWS

SPECIAL REQUIREMENTS TO SEALING SYSTEMS

POA – PRICE ON APPLICATION

Categories: ,

Description

  • Actuator allocation according to product pressure: 87psi (6 bar); 145psi (10 bar); 330psi (22.7 bar)
  • Valve disc with balancer
  • Housing PN 25 (360psi) free from dead space
  • Seal material EPDM compliant with FDA 21 CFR 117.2600- Optional HNBR, FKM, VMQ
  • Shaft seal – Resistance to rip-out; with stripping function
  • Metallic stop
  • Two-part valve disc – screwed with lock against rotation
  • Defined space requirements for the seal
